Large barrel filling line

Product introduction

This model is mainly used for filling large barrels and adopts weighing measurement, which makes up for the quantitative accuracy problems of traditional flowmeter filling machines and the inability to measure viscous liquids.

Large barrel weighing filling machine details page

Large barrel filling line

Product overview

Performance characteristics

Technical parameters

Product introduction

Main advantages

High-precision weighing and measurement

Suitable for viscous liquids

Special for vat filling

Make up for the shortcomings of traditional filling machines

Performance characteristics

High-precision weighing and measurement

Using the weighing measurement method, the measurement accuracy reaches ±1%, far exceeding the traditional flow meter filling machine.

Suitable for viscous liquids

It solves the problem that traditional flow meters cannot measure relatively viscous liquids, and has a wider range of applications.

Special for vat filling

Specially designed for large barrel filling, with a filling capacity of 50-300L, meeting large-capacity filling needs.

efficiency production capacity

The production capacity is about 50-80 barrels/hour, meeting the needs of large-scale production.

Overview of key parameters

Production parameters

production capacity About 50-80 barrels/hour

filling capacity 50-300L

Measuring accuracy ±1%

Physical parameters

Overall dimensions 2000(L)×1030(W)×2300(H)mm

Machine net weight 400kg

Electrical parameters

Supply voltage AC220V,50/60Hz

total power 3.5kw

Air source pressure 0.6-0.8Mpa

Main technical parameters

Parameter name	Parameter value	illustrate
production capacity	About 50-80 barrels/hour	efficient production
filling capacity	50-300L	Large capacity filling
Measuring accuracy	±1%	High-precision measurement
Air source pressure	0.6-0.8Mpa	Standard industrial air source
total power	3.5kw	Low energy consumption design
Supply voltage	AC220V,50/60Hz	Standard power supply
Applicable bottle diameter	Customized according to non-standard packaging materials	Flexible customization
Applicable bottle height	Customized according to non-standard packaging materials	Flexible customization
Machine net weight	400kg	Stable structure
Overall dimensions	2000(L)×1030(W)×2300(H)mm	Compact design

Application Notes

Specially designed for vat filling,Makes up for the lack of accuracy of traditional flow meter filling machines
useWeighing method, accuracy up to ±1%
solvedDifficulty measuring viscous liquidsquestion
Suitable for large-capacity filling of 50-300L,High production efficiency
Can be customized according to non-standard packaging materials.Adaptable
