Compactor
Product introduction
The compactor is a key equipment for the pretreatment of powder materials. It is mainly used to improve the density and fluidity of powder materials to prepare for subsequent processing or packaging processes. The equipment compresses the powder through mechanical pressure or vibration to reduce the gaps between particles, thereby improving the physical properties of the material.
Powder front processing equipment compactor
Product introduction
The compactor is a key equipment for the pretreatment of powder materials. It is mainly used to improve the density and fluidity of powder materials to prepare for subsequent processing or packaging processes. The equipment compresses the powder through mechanical pressure or vibration to reduce the gaps between particles, thereby improving the physical properties of the material.
Application areas
Performance characteristics
Efficient and compact
It can effectively increase the packing density of powder materials, enhance the fluidity and stability of materials, reduce dust flying, and improve the efficiency of subsequent processes.
Various ways of working
Using methods such as screw advancement, roller pressing or vibration compression, uniform pressure is applied to the powder to achieve densification.
structural design
The equipment is compact in structure, easy to operate and easy to maintain, including the feeding system, compression mechanism, control system and other parts.
High degree of automation
With high degree of automation, low energy consumption and strong adaptability, it is an important link in the modern powder processing process.
Overview of key parameters
Main technical parameters
| Parameter name | Parameter value | illustrate |
|---|---|---|
| processing power | 500-2000kg/h | Can be adjusted according to material characteristics |
| Increased density | 15-30% | Significantly increase bulk density |
| power | 5.5-15kW | Energy saving design |
| Compression pressure | 0.5-3.0MPa | Adjustable pressure range |
| Applicable material particle size | 0.1-5mm | Wide applicability |
| control system | PLC+touch screen | Intelligent control |
| Power requirements | AC380V 50Hz | Standard industrial power supply |
| Air source requirements | 0.6-0.8 MPa | Clean and dry air source |
Application Notes
- Chemical industry: Used for pretreatment of pigments, dyes, fertilizers and other powders to improve packaging and transportation efficiency
- pharmaceutical industry: Suitable for densification of medicinal powder to ensure dosage accuracy and production hygiene standards
- food industry: Used for front-end treatment of milk powder, starch, seasonings and other powders to improve processing performance
- Building materials industry: Used for densification of cement, fly ash and other materials to improve product quality
- Metallurgical industry: Processing metal powders to provide pretreatment for briquetting or sintering processes
- The device hasHigh degree of automation, low energy consumption and strong adaptabilityand other characteristics
